In servo system, do you know what should be paid attention to when grounding servo drive?

Eight points to note for grounding of servo drives are as follows:

? The correct shielding connection is at a reference potential point inside the circuit, which depends on whether the noise source and the receiver are both grounded or floating.

? Make sure that the shield is grounded at the same point so that the earth current does not flow through the shield.

? Avoid a variety of connection to the earth generated by the ground loop is easily affected by noise and generate current at different reference points.

? When the AC power supply is not isolated from the DC bus of the driver, do not connect the non-isolated port or signal of the DC bus to the ground, which may cause device damage and personal injury.

? Avoid servo drive to external power supply, will directly affect the work of the controller and the driver.

? The common voltage of AC is not to the ground. There may be a high voltage between the DC bus and the ground. Direct grounding is prohibited.

? In the servo system, the public ground and the earth must be connected together at the signal end.

? In order to keep the command reference voltage constant, to the servo driver signal ground to the controller signal ground.
